Q-112M QAM TransModulator 12xDVB-S2 IN / 4 DVB-C / DVB-T OUT

Works both Coax Cable & IPTV networks: Distribute MPEG-4 AVC encoding to all kinds of Modulation and All SPTS/ MPTS Over UDP IP out.

Operation via LCD Screen and Web Management : easy to read LCD color front panel that makes it easy to setup and monitor your channels, check firmware, and identify IP addresses without a computer.

 Multi-Modulation: Optional DVB-C (QAM), DVB-T (COFDM), ATSC-T, ISDB-T, DTMB Modulation (can selectable in web interface).

DVB-S2/S tuner: Support QPSK, 8PSK,16Apsk/ 32APSK, maximum Symbol rate 55MSps.

 Flexible selection of different input modules: four tuner, four HD encoding in one device

Features

• Distribute Up to 24 FTA  Tuners over RF  to an unlimited number of TVs
• Selectable DVB-S2, ISDB-T, DVB-C, DVB-T/T2, DTMB, ATSC free to air Tuners inputs
• DVB-S2 inputs support up to 16apsk, 32apsk (optional)
• Optional DVB-C (QAM), DVB-T (COFDM), ATSC-T, ISDB-T, DTMB Modulation, 4*Carrier RF Out, 8*carrier RF out (option)
• In modulation Mode, support 128*IP input
• Two separate ASI input for External TS Multiplexing
• Simulaneously 4*MPTS, N*tuner passthrough and 512*SPTS over UDP/RTP IP out in Tuners Gateway
• 4 separate multiplexing and Up-converter modulating adjacent carrier out
• Support BISS-1 and BISS-E decryption
• Selectable the Value of PCR PID same as Video PID
• LCN (Logical Channel Number) support
• PSI/SI editing & inserting; PID Remapping & Filtering
• Support TTL editing
• Support PCR correct and PCR interval adjusting
• Low power consumption and high reliability
• Easy-to-Use System Management via We


  Q112M

  12 (with 128 IP in)

  QAM; ATSC; DVB-T; ISDB; DTMB

  128*SPTS and 1*MPTS

• 1900
